干燥機的有何特點？

干燥機械是集干燥、粉碎、篩分于一體的新型連續式干燥設備，山東干燥機械具有設計合理，結構緊湊，使用范圍廣，可用于顏料、染料、精細化工、農藥、肥料、飼料、食品、醫藥、電子等化工輕工諸行業，含水量高的糊狀物料干燥。達到高效快速、節能、小設備大生產，連續化操作的目的。

Drying machinery is a new type of continuous drying equipment which integrates drying, crushing and screening. Shandong drying machinery has reasonable design, compact structure and wide application range. It can be used in pigment, dye, fine chemical industry, pesticide, fertilizer, feed, food, medicine, electronics and other chemical and light industries. It has high water content paste material drying. To achieve the purpose of high efficiency, fast, energy saving, large-scale production of small equipment, continuous operation

熱空氣由入口管以適宜的噴動速度從干燥機底部進入攪拌粉碎干燥室，對物料產生強烈的剪切、吹浮、旋轉作用，于是物料受到離心、剪切、碰撞、摩擦而被微?；?，強化了傳質傳熱。在干燥機底部，較大較濕的顆粒團在攪拌器的作用下被機械破碎，濕含量較低、顆粒度較小的顆粒被旋轉氣流夾帶上升，在上升過程中進一步干燥，由于氣固兩相作旋轉流動，固相慣性大于氣相，固氣兩相間的相對速度較大，強化兩相間的傳質傳熱，所以該機生產強度高。

The hot air enters the stirring and crushing drying chamber from the bottom of the dryer at an appropriate spouting speed from the inlet pipe, which exerts strong shearing, blowing and rotating effects on the materials. As a result, the materials are granulated by centrifugation, shearing, collision and friction, thus enhancing mass and heat transfer. At the bottom of the dryer, larger and wetter particles are mechanically broken under the action of the agitator. The particles with lower moisture content and smaller particle size are entrained and lifted by the rotating air flow. During the rising process, the gas-solid two-phase flow is rotating, the inertia of the solid phase is greater than that of the gas phase, and the relative velocity of the solid-gas phase is relatively large, which strengthens the mass transfer and heat transfer between the two phases High strength.

山東干燥機械的特點：

The characteristics of Shandong drying machinery are as follows

無機類：硼酸、碳酸鈣、氫氧化物、硫酸銅、氧化鐵、碳酸鋇、三氧化銻、各種金屬氫氧化物、各種重金屬鹽、合成冰晶石等；

Inorganic: boric acid, calcium carbonate, hydroxide, copper sulfate, iron oxide, barium carbonate, antimony trioxide, various metal hydroxides, various heavy metal salts, synthetic cryolite, etc;

有機物：阿特拉津（農藥殺蟲劑）、月桂酸隔、苯甲酸、安息香酸、殺菌丹、草酸鈉、醋酸纖維素等；

Organic matter: atrazine (pesticide and pesticide), lauric acid, benzoic acid, benzoic acid, fungicide, sodium oxalate, cellulose acetate, etc;

陶瓷：高嶺土、三氧化硅、粘土等；

Ceramics: kaolin, silica, clay, etc;

染料類：蒽醌、黑色氧化鐵、靛藍顏料、丁酸、氫氧化鈦、硫化鋅、各種偶氮染料中間體。

Dyes: anthraquinone, black iron oxide, indigo pigment, butyric acid, titanium hydroxide, zinc sulfide, intermediates of various azo dyes.

食品類：大豆蛋白、膠凝淀粉、酒糟、小麥糖、小麥淀粉等。

Food: soybean protein, gelatinous starch, distiller's grains, wheat sugar, wheat starch, etc.

1、多種加料裝置供選擇，加料連續穩定，過程中間不會(huì )產生架橋現象。

1. A variety of feeding devices for selection, continuous and stable feeding, no bridging phenomenon in the process.

2、干燥機底部設置特殊的冷卻裝置，避免了物料在底部高溫區產生變質現象。

2. A special cooling device is set at the bottom of the dryer to avoid the deterioration of materials in the high temperature area at the bottom.

3、特殊的氣壓密封裝置和軸承冷卻裝置，有效延長傳動部分使用壽命。

3. Special air pressure sealing device and bearing cooling device can effectively prolong the service life of transmission part.

4、特殊的分風裝置，降低了設備阻力，并有效提供了干燥器的處理風置。

4. The special air distribution device reduces the resistance of the equipment and effectively provides the treatment air device of the dryer.

5、干燥室裝有分級環及旋流片，物料細度和終水份可調。（如碳酸鈣終水份可調至≤0.1%）。

5. The drying chamber is equipped with a grading ring and a swirl plate, and the material fineness and final moisture can be adjusted. (if the final moisture content of calcium carbonate can be adjusted to ≤ 0.1%).

6、相對其它干燥方法而言，可有效增加物料比重。

6. Compared with other drying methods, it can effectively increase the specific gravity of materials.

7、干燥室內周向氣速高，物料停留時間短，有效防止物料粘壁及熱敏性物料變質現象，達到高效、快速、小設備、大生產。

7. The drying chamber has high circumferential gas velocity and short residence time of materials, which can effectively prevent materials from sticking to the wall and deterioration of heat sensitive materials, and achieve high efficiency, fast, small equipment and large-scale production.

8、由于物料受到離心、剪切、碰撞、摩擦而被微?；矢叨确稚顟B(tài)及氣固間的相對速度較大，強化傳熱傳質，使該機生產強度高。

8. Because of the high dispersion of the material and the high relative velocity between gas and solid, the heat and mass transfer are strengthened, which makes the production intensity of the machine high.

9、干燥氣體進入干燥機底部，產生強烈的旋轉氣流，對器壁上物料產生強烈的沖刷帶出作用，消除粘壁現象。

9. When the dry gas enters the bottom of the dryer, it produces a strong rotating air flow, which has a strong scouring effect on the materials on the wall of the dryer and eliminates the phenomenon of sticking to the wall.

10、在干燥機底部高溫區，熱敏性物料不與熱表面直接接觸，解決了熱敏性物料的焦化變色問題。

10. In the high temperature area at the bottom of the dryer, the heat sensitive materials do not contact with the hot surface directly, which solves the problem of coking discoloration of heat sensitive materials.

11、干燥室內置旋流片，以控制物料水分達到極低水平。

11. In order to control the moisture content of the material to a very low level, the rotary flow sheet is placed in the drying chamber.

12、干燥室上部分散器可以控制出口物料的粒度及濕度。

12. The upper part of the dryer can control the particle size and humidity of the outlet materials.

13、干燥強度大，適用膏糊狀和濾餅的干燥。

13. It is suitable for drying paste and filter cake.
