山東制氮機保養和檢查計劃

制氮機是根據可變壓力吸附技術設計，制造氮氣生產設備。制氮機以?xún)?yōu)質進口碳分子篩（CMS）為吸附劑，采用正常溫度壓力吸附原理（PSA）分離空氣，實現高純度氮。通常同時采用兩個吸附塔，通過進口PLC控制進口氣動閥自動操作，交替增壓減壓再生，完全氮氧分離，實現必要的氮氣高純度。

Nitrogen generator is based on variable pressure adsorption technology design, manufacturing nitrogen production equipment. The nitrogen generator uses high quality imported carbon molecular sieve (CMS) as adsorbent and adopts normal temperature and pressure adsorption principle (PSA) to separate air to realize high purity nitrogen. Usually, two adsorption towers are used at the same time. The imported PLC controls the automatic operation of the imported pneumatic valve, and the pressure is alternately increased and reduced to regenerate, and the nitrogen and oxygen are completely separated to achieve the necessary high purity of nitrogen.

制氮機深冷氮不僅可以產生氮氣，而且能產生液氮，滿足液氮工藝的需要，并可儲存在液氮儲罐中，當氮間歇性負荷或空氣分離設備進行維修時，蒸發器中罐中的液氮被加熱，輸入到產品氮氣管道中，滿足工藝單元對氮的需求。深冷氮生產運行周期（指兩大加熱間隔）一般為1年以上，因此深冷氮生產一般不考慮備件。而可變壓力吸附氮只能產生氮氣，沒有備用劑，一套設備不能保證連續長循環運行。

The cryogenic nitrogen of the nitrogen generator can not only produce nitrogen, but also produce liquid nitrogen, which can meet the needs of liquid nitrogen process, and can be stored in liquid nitrogen storage tank. When nitrogen intermittent load or air separation equipment is maintained, the liquid nitrogen in the evaporator tank is heated and input into the product nitrogen pipeline to meet the nitrogen demand of the process unit. The operation cycle of cryogenic nitrogen production (refers to the two heating intervals) is generally more than 1 year, so the production of cryogenic nitrogen generally does not consider spare parts. However, nitrogen can only be produced by adsorption of nitrogen under variable pressure, and there is no backup agent, so a set of equipment can not guarantee continuous long-term cycle operation.

山東制氮機保養和檢查計劃：

Shandong nitrogen generator maintenance and inspection plan:

一、檢查制氮機的管路是否出現泄漏,部件有無損壞等;

1、 Check whether there is leakage in the pipeline of nitrogen generator and whether the parts are damaged;

二、每隔兩個月左右就要對設備進行一個元器件方面的定點檢查,檢測是否出現異常和故障;

2、 Every two months or so, it is necessary to carry out a fixed-point inspection on the components of the equipment to detect whether there is any abnormality or failure;

三、分析分子篩的含量是否降低,很多制氮機的純度達不到純度就是因為這個原因引起;

3、 Analyzing whether the content of molecular sieve is reduced, the purity of many nitrogen generators can not reach the purity is caused by this reason;

四、每隔一年就要更換一次制氮機的濾芯,更換濾芯的時候要對設備進行泄壓,以免產生人身安全問題,更換過程中不能損壞濾芯中心的O型密封圈;

4、 The filter element of the nitrogen generator should be replaced every other year. When replacing the filter element, the pressure of the equipment should be relieved to avoid personal safety problems. The O-ring in the center of the filter element should not be damaged during the replacement process;

五、每年更換一次活性炭過濾器。

5、 Replace the activated carbon filter once a year.

制氮機以空氣作為原料，在一定的壓力條件下，使用氧氣和氮等不同特性的氣體在膜上有不同的滲透速率來分離氧氣和氮氣。與其他氮化設備相比，具有結構簡單、體積小、無離合器閥、維護少、氣體生產快（3分鐘）、容量增加方便等優點，特別適用于氮化純度為98%的中小型氮氣用戶，具有好的功能價格比。當氮單位超過98%時，比相同規格的PSA氮氣機貴15%以上。

The nitrogen generator uses air as raw material and uses gases with different characteristics such as oxygen and nitrogen to separate oxygen and nitrogen at different permeation rates on the membrane under certain pressure conditions. Compared with other nitriding equipment, it has the advantages of simple structure, small volume, no clutch valve, less maintenance, fast gas production (3 minutes) and convenient capacity increase. It is especially suitable for small and medium-sized nitrogen users with nitriding purity of 98%, and has good function price ratio. When the nitrogen unit is more than 98%, it is more than 15% more expensive than PSA nitrogen machine of the same specification.
