行業新聞

螺桿鼓風機如何控制排氣溫度?

來源:http://www.matsteinwede.com/   日期:2021-01-05   瀏覽量:0
TAG:山東制氮機,山東干燥機,山東螺桿鼓風機,山東空壓機,山東自動排水器

使用過程中,螺桿鼓風機會(huì )有出口溫度(溫升)過高的問題,那如果真空的發生這樣的問題的時候,又該如何去處理呢?

In the process of using, the outlet temperature (temperature rise) of screw blower is too high. How to deal with the problem of vacuum?

影響螺桿鼓風機出口溫度的因素包括:鼓風機的容積效率、工作壓力、內泄漏情況以及入口空氣溫度等。這些因素中,大部分和鼓風機的設計與工藝水平有關系,它們在鼓風機選型結束就已定型,難以改變,因此簡單的就是在降低工作壓力、入口溫度上進行考慮。

The factors that affect the outlet temperature of screw blower include volume efficiency, working pressure, internal leakage and inlet air temperature. Most of these factors are related to the design and process level of the blower. They have been finalized at the end of the selection of the blower and are difficult to change. Therefore, the simplest consideration is to reduce the working pressure and inlet temperature.

我們有一個簡單的螺桿鼓風機出口溫度判別方式,就是螺桿鼓風機的出口溫度≈入口溫度+(10~12)*壓力(壓力單位為米水柱)。舉個例子,污水曝氣中鼓風機的工作壓力為6米水深,管路及曝氣頭等的壓損約為1米水柱,環境溫度30℃,那么它的出口溫度就在:30+(10~12)*(6+1),也就是100~114℃之間。


We have a simple way to judge the outlet temperature of the screw blower, that is, the outlet temperature of the screw blower ≈ the inlet temperature + (10 ~ 12) * the pressure (the pressure unit is meter water column). For example, in sewage aeration, the working pressure of the blower is 6 meters deep, the pressure loss of the pipeline and aeration head is about 1 meter water column, and the ambient temperature is 30 ℃, then its outlet temperature is 30 + (10 ~ 12) * (6 + 1), that is, 100 ~ 114 ℃.

我們可以看到,鼓風機入口溫度和工作壓力的變化會(huì )直接影響到出口溫度的變化。因此,螺桿鼓風機出口溫度如果太高,就可以考慮能否降低工作壓力以及入口的空氣溫度:

We can see that the change of inlet temperature and working pressure of blower will directly affect the change of outlet temperature. Therefore, if the outlet temperature of screw blower is too high, we can first consider whether we can reduce the working pressure and the inlet air temperature

1、減少壓損。

1. Reduce pressure loss.

例子中我們可以看到壓力如果上升1米水柱,螺桿鼓風機的出口溫度會(huì )有所上升,因此,減少不必要的壓損,可以有效降低鼓風機的出口溫度,如來自管路設計產生的壓損、過濾器、曝氣頭等設備產生的壓損等等。

In the example, we can see that if the pressure rises by 1 m water column, the outlet temperature of the screw blower will rise. Therefore, reducing unnecessary pressure loss can effectively reduce the outlet temperature of the blower, such as pressure loss from pipeline design, pressure loss from filters, aeration head and other equipment, etc.

2、降低入口溫度。

2. Lower the inlet temperature.

螺桿鼓風機大多安裝在室外,因此需要保證良好的通風,同時避免接近其他熱源,以降低環境溫度與鼓風機入口溫度;如果風機是裝在室內的,有條件的可以裝空調,不僅可以降低設備入口空氣溫度,進而降低出口排氣溫度,同時也可以延長電機等設備的壽命。

Most screw blowers are installed outdoors, so it is necessary to ensure good ventilation and avoid approaching other heat sources to reduce the ambient temperature and the inlet temperature of the blower; if the fan is installed indoors, air conditioning can be installed if conditions permit, which can not only reduce the inlet air temperature of the equipment, but also reduce the outlet exhaust temperature, and prolong the service life of the motor and other equipment.

3、裝有隔音罩的,必要時打開隔音罩,如在夏天時。

3. If equipped with acoustic enclosure, open the acoustic enclosure if necessary, such as in summer.

很多的隔音罩起不到明顯的隔音作用,倒是可能因封閉的環境導致內部溫度增高,從而使鼓風機入口溫度偏高,進而影響出口排氣溫度。所以在必要的場合,可以打開或放棄隔音罩。

A lot of noise enclosures do not play a significant role in sound insulation, but the internal temperature may increase due to the closed environment, which will make the inlet temperature of the blower higher, and then affect the outlet exhaust temperature. So in the necessary occasions, you can open or give up the acoustic enclosure.

鼓風機出口溫度太高在很多領域會(huì )影響下一步生產作業,如在曝氣領域會(huì )影響氧溶解以及微生物的生存環境等,因此在發現出口排氣溫度過高時應該及時處理。

If the outlet temperature of the blower is too high, it will affect the next production operation in many fields, such as in the aeration field, it will affect the oxygen dissolution and the living environment of microorganisms, so it should be dealt with in time when the outlet exhaust temperature is too high.

標簽: 山東螺桿鼓風機


上一篇:如何拆卸空壓機的減荷閥?
下一篇:影響污泥干燥機工作效率的外部因素有哪些?
